Field-Testing Begins on Version 9.1 Enhancements

Field-testing and validation of Version 9.1 is now underway! The simulation technologies and features contained in this update will provide HVE, HVE-2D and HVE-CSI users with new powerful capabilities. The short list of enhancements includes:


Trailer Separation in SIMON • Simulation of trailer disconnection resulting from mechanical failure or collision forces/moments will be possible. The robust handling of the vehicles post-separation allows for detailed study of a trailer's free-rolling trajectory, roll-over and collisions with other objects.

Key Results Display in Video Creator • The Video Creator viewer will include a Key Results window that displays time-domain results which are recorded directly in your simulation movie. The available Key Results include all the standard results (e.g., time, positions, velocities, accelerations, forces...).

DXF Support in HVE-CSI Users will be able to select Aerial Photo or Terrain as environment models used in HVE-CSI. If Terrain is selected, an AutoCAD DXF format line drawing or 2-D surfaced model can be imported directly into the Environment Editor. This capability allows for quick placement of vehicles over scene evidence in EDCRASH reconstructions by switching to wireframe mode as shown.

Third-Party Vehicle Database License Manager • License mangement of vehicles selected from a third party database provider, such as those available from Vehiclemetrics, will be supported.

These are just a few of the new technologies and features available in Version 9.1. For more information about the enhancements for HVE, HVE-2D and HVE-CSI, contact EDC at 888.768.6216.
